Migration Guide: Adobe Express Embed SDK V3 to V4

This guide will assist you in updating your Adobe Express Embed SDK integration from V3 to v4.

Overview

Adobe Express Embed SDK V4 introduces a more verbose set of APIs, simplifies parameters, and removes redundancies.

Breaking Changes

Update SDK version from V3 to V4
Restructure initialization parameters (3 parameters instead of 2)
Move callbacks from API-level to class-level
Replace single APIs with workflow-specific methods
Update parameter structure (4 new parameter types)

API Mapping

createDesign() → editor.create(), editor.createWithAsset(), or editor.createWithTemplate()
editDesign() → editor.edit()
openQuickAction() → specific quickAction.*() methods

Parameter Changes

Separate mixed parameters into: DocConfig, AppConfig, ExportConfig, ContainerConfig
Merge userInfo and authInfo into single authOption
Remove quickActionId (use specific methods instead)

Optional Enhancements

Enable V2 module features (if using modules)
Review new workflow capabilities
Update internal documentation

Understanding V4 Workflows

In V3, there were three main APIs: createDesign(), EditDesign(), and openQuickActions(). These APIs differentiated user intent by analyzing parameters provided by partner teams, subsequently initiating the appropriate workflow. However, this approach increased the parameters for each API, as they were designed to cater to multiple user intents.

We have addressed this issue in V4 by segmenting the APIs into workflows based on user intent and providing more descriptive API names.

The three workflows are as follows:

Module Workflow - For focused editing tasks
Editor Workflow - For full design creation and editing
Quickaction Workflow - For quick image/video transformations

API Migration Overview

The following diagram shows how the previous API relates to the current new APIs:

V3 V4 API Migration Overview

Parameter Restructuring

V4 introduces a cleaner parameter structure with four distinct parameter types instead of mixed parameters:

V3 to V4 Parameter Migration

The four parameters are:

DocConfig - Describes the starting point of a workflow, for example, canvas size for Express Editor.
AppConfig - properties that configure the target application starting behaviour.
ExportConfig - properties that govern the export behaviour of a workflow.
ContainerConfig - UI properties that customize the SDK container.

Example transformation:

V3: ccEverywhere.createDesign(inputParams);

V4: ccEverywhere.editor.create(docConfig, appConfig, exportConfig, containerConfig);

Complete API Reference

New V4 APIs by Workflow

Module Workflow (New in V4)

V4 API	Description
`CCEverywhere.module.editImage`	Start editing an asset using image module
`CCEverywhere.module.createImageFromText`	Generate images using text prompts with mini editing experience

Editor Workflow

V3 API	V4 API	Description
`createDesign()` (blank canvas)	`CCEverywhere.editor.create()`	Initiates workflow using blank canvas
`createDesign()` (with asset)	`CCEverywhere.editor.createWithAsset()`	Preloads image asset onto canvas
`createDesign()` (with template)	`CCEverywhere.editor.createWithTemplate()`	Starts with Adobe Express template ID
`editDesign()`	`CCEverywhere.editor.edit()`	Modifies existing Adobe Express Document

Quick Action Workflow

V3 API	V4 API Examples	Description
`openQuickAction()` (with ID)	`CCEverywhere.quickAction.cropImage()`	Individual methods for each action
	`CCEverywhere.quickAction.convertToJPEG()`	Convert image to JPEG format
	`CCEverywhere.quickAction.convertToPNG()`	Convert image to PNG format
	`CCEverywhere.quickAction.resizeImage()`	Resize image dimensions

Deprecated Features

APIs: createDesign(), editDesign(), openQuickAction()
Parameters: quickActionId, mixed input parameters, API-level callbacks
Auth structure: Separate userInfo and authInfo (now merged into authOption)

Step-by-Step Migration Guide

Now that you understand the conceptual changes, let's walk through the practical migration steps:

1:Update SDK Version

First, update your script tag or import statement to use the V4 SDK.

Find the latest version: Check https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js for the current version number.

version

V4 HTML Script Tag

V3 HTML Script Tag

npm/Bundler Import Update

<!-- V4 - Updated version -->
<script src="https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js"></script>
Copied to your clipboard
<!-- V4 - Updated version -->
<script src="https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js"></script>

<!-- V3 - Previous version -->
<script src="https://cc-embed.adobe.com/sdk/v3/CCEverywhere.js"></script>
Copied to your clipboard
<!-- V3 - Previous version -->
<script src="https://cc-embed.adobe.com/sdk/v3/CCEverywhere.js"></script>

// V4 - Updated import
import CCEverywhere from '@adobe/cc-everywhere-sdk/v4';

// Alternative CDN import for modules
await import("https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js");

// V3 - Previous import
import CCEverywhere from '@adobe/cc-everywhere-sdk/v3';
Copied to your clipboard

// V4 - Updated import
import CCEverywhere from '@adobe/cc-everywhere-sdk/v4';

// Alternative CDN import for modules
await import("https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js");

// V3 - Previous import
import CCEverywhere from '@adobe/cc-everywhere-sdk/v3';

2: Update Initialization Code

Update your initialization code to use the new configuration parameters.

Notable changes to parameters at Initialize level:

Host Info
Config Params: Login Mode has moved from configParams to AuthInfo / AuthProvider.
User Info and Auth Info: Both of these params are merged into one, AuthInfo.

Callbacks

We have moved callbacks from an API-level to a class-level parameter. This enables partners to pass their callbacks once during the lifecycle of SDK. The list of callbacks supported by SDK remains the same as it was in V3.

Key Changes:

3 parameters instead of 2: Added authOption as third parameter
Merged auth parameters: userInfo and authInfo combined into authOption
Callbacks moved to class-level: Set once during initialization instead of per API call

V3 HTML Script Tag

V4 HTML Script Tag

V3 vs V4 TypeScript Signatures

<script src="https://cc-embed.adobe.com/sdk/v3/CCEverywhere.js"></script>
<script>
  // V3 Initialization
  const ccEverywhere = await window.CCEverywhere.initialize(
    { clientId: "your-client-id", appName: "your-app-name" },
    { /* configParams */ }
  );
</script>
Copied to your clipboard
<script src="https://cc-embed.adobe.com/sdk/v3/CCEverywhere.js"></script>
<script>
  // V3 Initialization
  const ccEverywhere = await window.CCEverywhere.initialize(
    { clientId: "your-client-id", appName: "your-app-name" },
    { /* configParams */ }
  );
</script>

<script src="https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js"></script>
<script>
  // V4 Initialization with enhanced parameters
  const ccEverywhere = await window.CCEverywhere.initialize(
    { clientId: "your-client-id", appName: "your-app-name" }, // hostInfo
    { /* configParams */ }, // configParams
    { /* merged auth options */ } // authOption
  );
</script>
Copied to your clipboard
<script src="https://cc-embed.adobe.com/sdk/v4/CCEverywhere.js"></script>
<script>
  // V4 Initialization with enhanced parameters
  const ccEverywhere = await window.CCEverywhere.initialize(
    { clientId: "your-client-id", appName: "your-app-name" }, // hostInfo
    { /* configParams */ }, // configParams
    { /* merged auth options */ } // authOption
  );
</script>

// V3 - Basic initialization
initialize: (hostInfo: HostInfo, configParams?: ConfigParams) => Promise<CCEverywhere>

// V4 - Enhanced initialization with merged auth
initialize: (
  hostInfo: HostInfoSpecifiedBase,
  configParams?: ConfigParamsBase,
  authOption?: AuthOption
) => Promise<CCEverywhere>
Copied to your clipboard
// V3 - Basic initialization
initialize: (hostInfo: HostInfo, configParams?: ConfigParams) => Promise<CCEverywhere>

// V4 - Enhanced initialization with merged auth
initialize: (
  hostInfo: HostInfoSpecifiedBase,
  configParams?: ConfigParamsBase,
  authOption?: AuthOption
) => Promise<CCEverywhere>

3: Migrate Your API Calls

The most significant change in V4 is the move from single APIs to workflow-specific methods. Here's how to migrate each type:

Editor workflow API migration

V3 createDesign - Single API

V4 editor.create - Blank Canvas

V4 Specific Methods - Templates & Assets

// V3 - Single API with complex parameters
const result = await ccEverywhere.createDesign({
  callbacks: {
    onCancel: () => console.log('Cancelled'),
    onPublish: (publishParams) => console.log('Published', publishParams),
    onError: (err) => console.log('Error', err)
  },
  inputParams: {
    // Mixed parameters for different intents
    canvasSize: { width: 800, height: 600 },
    templateId: 'some-template-id',
    assetId: 'some-asset-id'
  }
});
Copied to your clipboard
// V3 - Single API with complex parameters
const result = await ccEverywhere.createDesign({
  callbacks: {
    onCancel: () => console.log('Cancelled'),
    onPublish: (publishParams) => console.log('Published', publishParams),
    onError: (err) => console.log('Error', err)
  },
  inputParams: {
    // Mixed parameters for different intents
    canvasSize: { width: 800, height: 600 },
    templateId: 'some-template-id',
    assetId: 'some-asset-id'
  }
});

// V4 - Separate method for blank canvas
const result = await ccEverywhere.editor.create(
  { canvasSize: { width: 800, height: 600 } }, // docConfig
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);
Copied to your clipboard
// V4 - Separate method for blank canvas
const result = await ccEverywhere.editor.create(
  { canvasSize: { width: 800, height: 600 } }, // docConfig
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

// V4 - For templates:
const result = await ccEverywhere.editor.createWithTemplate(
  { templateId: 'some-template-id' }, // docConfig
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

// V4 - For assets:
await ccEverywhere.editor.createWithAsset(
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);
Copied to your clipboard
// V4 - For templates:
const result = await ccEverywhere.editor.createWithTemplate(
  { templateId: 'some-template-id' }, // docConfig
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

// V4 - For assets:
await ccEverywhere.editor.createWithAsset(
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

Quick Action workflow API migration

V3 openQuickAction - Single API with ID

V4 quickAction - Specific Methods

// V3 - Single API with action ID
const result = await ccEverywhere.openQuickAction({
  quickActionId: 'crop-image',
  inputParams: {
  },
  callbacks: {
    onCancel: () => console.log('Cancelled'),
    onPublish: (publishParams) => console.log('Published', publishParams)
  }
});
Copied to your clipboard
// V3 - Single API with action ID
const result = await ccEverywhere.openQuickAction({
  quickActionId: 'crop-image',
  inputParams: {
  },
  callbacks: {
    onCancel: () => console.log('Cancelled'),
    onPublish: (publishParams) => console.log('Published', publishParams)
  }
});

// V4 - Specific method for each action (no ID needed)
const result = await ccEverywhere.quickAction.cropImage(
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

// Other quick actions available:
await ccEverywhere.quickAction.convertToJPEG(docConfig, appConfig, exportConfig, containerConfig);
await ccEverywhere.quickAction.convertToPNG(docConfig, appConfig, exportConfig, containerConfig);
await ccEverywhere.quickAction.resizeImage(docConfig, appConfig, exportConfig, containerConfig);
Copied to your clipboard
// V4 - Specific method for each action (no ID needed)
const result = await ccEverywhere.quickAction.cropImage(
  { /* app configuration */ }, // appConfig
  { /* export settings */ }, // exportConfig
  { /* UI customization */ }  // containerConfig
);

// Other quick actions available:
await ccEverywhere.quickAction.convertToJPEG(docConfig, appConfig, exportConfig, containerConfig);
await ccEverywhere.quickAction.convertToPNG(docConfig, appConfig, exportConfig, containerConfig);
await ccEverywhere.quickAction.resizeImage(docConfig, appConfig, exportConfig, containerConfig);

For complete API reference and all available methods, see:

4: Update Parameter Structure

V4 uses a consistent four-parameter structure across all APIs. Here's how to restructure your existing parameters:

Parameter restructuring:

V3 Mixed Parameters Structure

V4 Separated Parameter Structure

// V3 - Mixed parameters in single object
const v3Params = {
  callbacks: { /* callbacks */ },
  inputParams: {
    canvasSize: { width: 800, height: 600 },
    exportOptions: { format: 'jpeg' },
    containerStyle: { backgroundColor: 'white' }
  }
};

// Usage
await ccEverywhere.createDesign(v3Params);
Copied to your clipboard
// V3 - Mixed parameters in single object
const v3Params = {
  callbacks: { /* callbacks */ },
  inputParams: {
    canvasSize: { width: 800, height: 600 },
    exportOptions: { format: 'jpeg' },
    containerStyle: { backgroundColor: 'white' }
  }
};

// Usage
await ccEverywhere.createDesign(v3Params);

// V4 - Organized into four distinct parameter objects
const docConfig = { canvasSize: { width: 800, height: 600 } };
const appConfig = { /* application settings */ };
const exportConfig = { format: 'jpeg' };
const containerConfig = { backgroundColor: 'white' };

// Usage (callbacks moved to initialization)
await ccEverywhere.editor.create(docConfig, appConfig, exportConfig, containerConfig);
Copied to your clipboard
// V4 - Organized into four distinct parameter objects
const docConfig = { canvasSize: { width: 800, height: 600 } };
const appConfig = { /* application settings */ };
const exportConfig = { format: 'jpeg' };
const containerConfig = { backgroundColor: 'white' };

// Usage (callbacks moved to initialization)
await ccEverywhere.editor.create(docConfig, appConfig, exportConfig, containerConfig);

5: Enable V2 Module Features (Optional)

If you want to access the latest module features with enhanced capabilities, you need to enable V2 modules by setting appVersion to "2" in your app configuration:

V1 Module Configuration (Default)

V2 Module Configuration (Enhanced)

// V1 - Default module experience
const appConfig = {
  // appVersion not specified defaults to V1
  // ... other app configuration
};

// Standard module functionality
const result = await ccEverywhere.module.createImageFromText(
  { prompt: 'A beautiful sunset over mountains' }, // docConfig
  appConfig, // V1 configuration
  exportConfig,
  containerConfig
);
Copied to your clipboard
// V1 - Default module experience
const appConfig = {
  // appVersion not specified defaults to V1
  // ... other app configuration
};

// Standard module functionality
const result = await ccEverywhere.module.createImageFromText(
  { prompt: 'A beautiful sunset over mountains' }, // docConfig
  appConfig, // V1 configuration
  exportConfig,
  containerConfig
);

// V2 - Enhanced module features
const appConfig = {
  appVersion: "2", // This enables V2 module features
  // Additional V2-specific configurations:
  featureConfig: {
    "community-wall": true,
    "fast-mode": true
  },
  thumbnailOptions: ["rich-preview", "edit-dropdown"]
};

// Enhanced V2 module functionality
const result = await ccEverywhere.module.createImageFromText(
  { prompt: 'A beautiful sunset over mountains' }, // docConfig
  appConfig, // V2 configuration with enhanced features
  exportConfig,
  containerConfig
);
Copied to your clipboard
// V2 - Enhanced module features
const appConfig = {
  appVersion: "2", // This enables V2 module features
  // Additional V2-specific configurations:
  featureConfig: {
    "community-wall": true,
    "fast-mode": true
  },
  thumbnailOptions: ["rich-preview", "edit-dropdown"]
};

// Enhanced V2 module functionality
const result = await ccEverywhere.module.createImageFromText(
  { prompt: 'A beautiful sunset over mountains' }, // docConfig
  appConfig, // V2 configuration with enhanced features
  exportConfig,
  containerConfig
);

Note: Setting appVersion: "2" is separate from the V3→V4 SDK migration but is required to access the full range of new module capabilities. This step is only relevant if you're using module workflows.

V2 Module Enhancements:

Generate Image V2 features:

Community Wall with user-generated inspiration
Fast Mode for quicker generation
Rich Preview for better image viewing
Thumbnail Actions for immediate editing
Custom Firefly Models (enterprise feature)

Edit Image V2 features:

35-50% reduced load times
35% reduced memory consumption
Redesigned UI with Adobe Spectrum 2
Tabbed interface for better organization

For detailed information on V2 module features and configuration options:

Generate Image V2 Guide: Complete guide for the enhanced text-to-image experience
Edit Image V2 Guide: Complete guide for the improved image editing experience

6: Test Your Implementation

After updating your code, thoroughly test your implementation to ensure everything works as expected. Pay particular attention to:

Initialization: Ensure the SDK initializes correctly with the new configuration parameters.
API Calls: Validate that all API calls function as intended with the updated method signatures and parameters.
Event Handling: Verify that events are being handled correctly and that any callbacks are working as expected.
User Interactions: Test all user interactions within the embedded content to ensure they are smooth and error-free.
Performance: Monitor the performance to confirm that the enhancements in V4 are realized in your application.

Here are some specific tests you can perform:

Initialization tests

Ensure the SDK correctly initializes with the initialize method.
Verify that the iframe is appended to the correct parent element.
Check that the iframe size, padding, border radius, and background color are applied as specified.

Full editor API tests

Test loading a template or design using create, createWithAsset, and createWithTemplate.
Validate that the editor sets the default category, search text, template type, and titles correctly.
Ensure that export options, multi-page settings, allowed file types, and image quality settings are applied properly.

Quick action API tests

Test various Quick action APIs such as image and video editing.
Validate that standard inputs for Quick Actions are working correctly.
Ensure that API-specific parameters are applied and functioning as expected.

Modules API tests

Test loading an asset in the modules using editImage or createImageFromText.
Verify that the asset is displayed and editable.
Check that export options and allowed file types are correctly configured.

7: Explore New V4 Features

Take advantage of new features introduced in V4:

New V4 Features:

Module Workflow: New editImage and createImageFromText capabilities
Enhanced Editor APIs: More granular control with separate create methods
Individual Quick Actions: Specific methods for each quick action type
Improved Parameter Structure: Cleaner separation of concerns with four parameter types
Class-level Callbacks: Set callbacks once during initialization instead of per API call

Additional Resources:

V4 Release Notes: Complete list of changes and improvements
V4 API Reference: Full documentation of all V4 APIs
Troubleshooting Guide: Common issues and solutions during migration

Some new features might include:

Enhanced configuration options for better customization.
New methods and parameters to provide more control over the SDK.
Improved performance and security features.

8: Update Documentation and Dependencies

Ensure your internal documentation is updated to reflect the changes made during the migration. Also, update any dependencies interacting with Adobe Express Embed SDK to ensure compatibility. This includes:

Updating any code samples or snippets in your documentation.
Modifying any integration guides or setup instructions.
Ensuring all team members know the changes and how to use the new SDK features.

Migration Summary

Congratulations! You've successfully migrated from Adobe Express Embed SDK V3 to V4. Here's what you've accomplished:

✅ Core Migration Complete

Updated SDK version from V3 to V4
Restructured initialization with new 3-parameter structure
Migrated API calls to workflow-specific methods
Reorganized parameters into the new 4-parameter structure

🎯 Key Benefits Achieved

Cleaner API structure with workflow-based organization
Better parameter separation for easier maintenance
Enhanced functionality with new module capabilities
Improved performance and scalability

📚 Next Steps

If you encounter any issues during migration, consult our Troubleshooting Guide for common solutions.

For ongoing development, bookmark these essential resources:

V4 API Reference - Complete V4 documentation
V4 Release Notes - Latest updates and features
Migration Checklist - Review completed items

API References

CCEverywhere

Once you have successfully initialized the SDK, a Promise will be returned containing the CCEverywhere object.

Editor API

Provides API References for /Editor API.

Module API

Provides API References for /Module API.

Quick Action API

Provides API References for /Quick Action API.

Editor Customization

Error handling

Last updated 7/9/2025

Was this helpful?

Yes
